Adrenalin works very closely with Atair Canopies who make the renowned Troll base canopy.


After adding your product to the cart, download and complete the order form at the bottom of the page and send it to : commande@adrenalinbase.com

Adrenalin works very closely with Atair Canopies who make the renowned Troll base canopy.

After adding your product to the cart, download and complete the order form at the bottom of the page and send it to : commande@adrenalinbase.com

The Troll is a low aspect ratio 7-cell canopy that is built with the highest quality materials and is heavily reinforced in crucial high load areas. This enables it to withstand the heavy demands of modern day BASE-jumping. The profile of the Troll allows comfortable openings, great canopy rides and precision landings.
The Troll’s unique aerofoil is slightly tapered on the upper surface. This makes for a more efficient wing with less drag. All Troll canopies have Dacron lines, a unique tail pocket design that allow the lines to be securely stowed.
A great match for an AdrenalinBase container.

MDV System

The vents system on the Atair Canopies is called Mono Directional Valve technology or MDV technology. This design allows the air to flow in, from the bottom surface, during pressurization and also during deep brake descent. The vents closes when air is rushing in from the nose and avoids back pressure coming from the tail.The MDV offers faster complete pressurization, specially on « slider down » jumps, more stability by increasing the range in which you can fly in deep brakes before you actually reach the stall point.Faster complete pressurization means less altitude loss during opening, but also better on heading performance and give to the jumper control over the canopy immediately.
MDV system can be chosen according to the primary use of the canopy. The original system, with 5 cells MDV remains the best compromise to get the most all-around canopy.
From 2013, it is also possible to have the system MDV on 1 or 3 cells, including always the center cell (benefit of inflation from center is on heading deployment). This choice will meet the different sub-terminal speeds.

5 MDV : (standard) : best configuration for slider down opening. Can be also jumped slider up.
3 MDV : compromise between 1 or 5. it will reduce inflation speed compare to 5 vents.
1 MDV : faster inflation of the center cell. Good for subterminal/terminal.

ZP nose

Used on the Trango canopy since 2008, this improvement had proven to help to keep the original lift on deep brake approaches and also more power for the landing flare during the entire life of the canopy. It's now available on the Troll

Light fabric

The light fabric used on the Trango is now available on all Atair Canopies. This fabric offers approximately a 25% reduction in packing volume and weight, without significantly reducing the resistance and lifespan of the canopy.

Vectran lines

the Vectran lines are very good to gain weight and volume, but due to the characteristic of the Vectran, it's a setup for slide up jumps only.

TROLL STANDARD

  • F111 material
  • White Dacron lines
  • 2 stage brakes setting
  • Control lines in different color
  • Big mesh slider
  • Tail Gate system

OPTIONS

  • Lightweight material
  • MDV 1,3 or 5 cells
  • Black Dacron lines
  • Vectran lines *
  • ZP nose
  • Black reinforcement tapes, thread and slider
  • Slow slider
  • Small mesh slider

* for slider up jumps only
